KIT MONOS4

KIT electromechanical actuator with telescopic arm, BRUSHLESS low voltage, super intensive use, with native encoder on-board, irreversible, ideal for swing gates with leaf up to 4 m. Complete with short brackets to screw on. With 2-channel radio receiver installed on board.

• Power line supply: 230V AC - 50Hz
• Stand-by consumption: ≤ 0,5W
• Motor power supply: 24V
• Power rating: 200W
• Frequency of use: Intensive use
• Thrust: 2200N
• Operating temperature: -20 C° +55 C°
• Protection level: IP44
• Reductor Type: Irreversible
• Manoeuvre speed: 2,10 cm/s
• Opening time: 19-35 s
• Stroke: 400 mm
• Limit switch: -
• Recommended digital controllers: -
• Encoder: Digital native encoder SENSORLESS 48 PPR
• Operating cycles per day (opening/closing - 24 hours no stop): 700
• Maximum dimension product in mm (L x W x H): 1223 x 178 x 111
• Product weight packed (Kg): 18,8
• Number items per pallet/box: 21
