| Model |
T-60DTBV |
| Output |
4-16Ω, 100V |
| RMS Power |
60W |
| Input Sensitivity & Impedance |
MIC1, 2, 3, 4 input: 5mV/600Ω, unbalanced 6.3 connector; |
| AUX1, 2 input: 350mV/10KΩ, unbalanced RCA connector; |
| EMC input: 775mV/10KΩ, unbalanced 6.3 connector |
| Output Sensitivity & Source Impedance |
MIX OUT: 1000mV/470Ω, unbalanced RCA connector |
| Tone |
Bass: ±10dB at 100Hz; |
| Treble: ±10dB at 10KHz |
| Frequency Response |
50Hz~16KHz(+1dB,-3dB) |
| SNR |
MIC1, 2, 3: 66dB; AUX1, 2: 80dB |
| THD |
Less than 0.5%( at 1KHz, 1/3 rated power) |
| Mute Control |
MIC 1 priority over MIC2-4, AUX1-2 audio input; |
| EMC has highest priority |
| Channel Crosstalk Attenuation |
≥50dB |
| Heat Dissipation |
Flank in and rear panel out to force fan cooling, fan starts when amplifier turned on, infinitely variable speed |
| Protection |
Over-heat, overload, short circuit |
| Power Supply |
AC ~220-240V /50Hz |
| Power Consumption |
120W |
| Dimension |
484x300x44mm |
| Weight |
3.5 Kg |
